STW40N95DK5
manufacturer:
STMicroelectronics
Description:
MOSFET N-CHANNEL 950V 38A TO247
Category:
Semiconductor IC
Specifications
Category:
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single FETs, MOSFETs
FET Feature:
-
Vgs(th) (Max) @ Id:
5V @ 100µA
Operating Temperature:
-55°C ~ 150°C
Package / Case:
TO-247-3
Gate Charge (Qg) (Max) @ Vgs:
100 NC @ 10 V
Rds On (Max) @ Id, Vgs:
130mOhm @ 19A, 10V
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
10V
Package:
Tube
Drain To Source Voltage (Vdss):
950 V
Vgs (Max):
±30V
Product Status:
Active
Input Capacitance (Ciss) (Max) @ Vds:
3480 PF @ 100 V
Mounting Type:
Through Hole
Series:
MDmesh™ DK5
Supplier Device Package:
TO-247
Mfr:
STMicroelectronics
Current - Continuous Drain (Id) @ 25°C:
38A (Tc)
Power Dissipation (Max):
450W (Tc)
Technology:
MOSFET (Metal Oxide)
Base Product Number:
STW40
Highlight:
STW40N95DK5 power MOSFET
,STW40N95DK5 semiconductor IC
,STW40N95DK5 high voltage transistor
Introduction
N-Channel 950 V 38A (Tc) 450W (Tc) Through Hole TO-247
