STTH1512G-TR
manufacturer:
STMicroelectronics
Description:
DIODE GEN PURP 1.2KV 15A D2PAK
Category:
Semiconductor IC
Specifications
Category:
Discrete Semiconductor Products
Diodes
Rectifiers
Single Diodes
Product Status:
Active
Current - Reverse Leakage @ Vr:
15 µA @ 1200 V
Mounting Type:
Surface Mount
Voltage - Forward (Vf) (Max) @ If:
2.1 V @ 15 A
Package:
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Series:
-
Capacitance @ Vr, F:
-
Supplier Device Package:
D²PAK
Reverse Recovery Time (trr):
105 Ns
Mfr:
STMicroelectronics
Technology:
Standard
Operating Temperature - Junction:
175°C (Max)
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Voltage - DC Reverse (Vr) (Max):
1200 V
Current - Average Rectified (Io):
15A
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Base Product Number:
STTH1512
Highlight:
STTH1512G-TR diode semiconductor
,STTH1512G-TR rectifier IC
,STTH1512G-TR power diode
Introduction
Diode 1200 V 15A Surface Mount D²PAK
